In this section, you will find:

  • API Usage Requirements
  • Trying out an API Example
  • cURL Output

API Usage Requirements

To use an API, you must pass in a required HTTP Header of ucsb-api-key to that API Resource URL. Continue on to see how this is used when you call an API.

Trying out an API Example

Let's take a look at how to use the Academic Quarter Calendar API. Click on the APIs link in the top navigation menu, then click on Academic.

Next, click on the Academic Quarter Calendar link to view its documentation.

Academic" />

This API has a couple GET methods. Click on the GET method for /quartercalendar/v1/sessions/current:

Academic Quarter Calendar Detail

Next, click Try it out.

Academic Quarter Calendar - Try it Out

Review the /quartercalendar/v1/sessions/current documentation.

Note that different APIs will have different Query Parameters or even other Path and Header Parameters depending on their unique requirements, but all APIs will require the ucsb-api-key HTTP Header.

Let's establish our API Key now by clicking on the Authorize button:

accessing the employee map API

Enter ucsb-api-key as the name and insert your app Consumer Key from your My First App page as the value and then click Authorize.

entering your consumer Key

Let's click on Send this request to perform the network request. If all went well and the id is valid, you should see a response from the UCPath Employee Map API like this:

  "quarter": "20192",
  "qyy": "S19",
  "name": "SPRING 2019",
  "category": "SPRING",
  "academicYear": "2018-2019",
  "firstDayOfClasses": "2019-04-01T00:00:00",
  "lastDayOfClasses": "2019-06-07T00:00:00",
  "firstDayOfFinals": "2019-06-08T00:00:00",
  "lastDayOfFinals": "2019-06-14T00:00:00",
  "firstDayOfQuarter": "2019-04-01T00:00:00",
  "lastDayOfSchedule": "2019-06-23T00:00:00",
  "pass1Begin": "2019-02-19T09:00:00",
  "pass2Begin": "2019-02-28T09:00:00",
  "pass3Begin": "2019-03-11T09:00:00",
  "feeDeadline": "2019-03-15T00:00:00",
  "lastDayToAddUnderGrad": "2019-04-19T00:00:00",
  "lastDayToAddGrad": "2019-04-19T00:00:00",
  "lastDayThirdWeek": null

Note: If your API key is invalid or if you've entered it incorrectly, you'll see an error like this:

  "fault": {
    "faultstring": "Invalid ApiKey for given resource",
    "detail": {
      "errorcode": "oauth.v2.InvalidApiKeyForGivenResource"

cURL Output

For completeness, you can scroll down to the cURL area to view the full HTTP Request sent via cURL:

cURL preview

Congratulations! You have just completed your first API call.
